SUNBAR 2000 FC - High power LED strobe

530200200
High power LED strobe, 1024x1W RGBW LED, 120°beam, 1126k lm, 987W

SunBar 2000FC is an exceptionally powerful LED graphic strobe batten featuring also as static blinder and flood. SunBar 2000FC offers flexible control of beam coverage through an interchangeable lens system, passing from 120° wide to 40° beam increasing the light intensity up to x4.

Available in FC / RGBW versions and designed to deliver simply staggering light levels, this versatile fixture can provide an unbelievable punch over a huge area.

Technical Specifications
LIGHT SOURCE
  • Source: 1.024x1W RGBW LEDs
  • CCT: W: 6.500K
  • Luminous flux: Strobe without lens (peak) 126000 lm; Static ON without lens 28834; Strobe with lens (peak) 46200; Static ON with lens 27188lm
  • Lux: (120°) 1'139 lx - (40°) 4'152lx @3 m full
  • Lux: (120°) 410,1 lx - (40°) 1'495lx @5 m full
  • Source life expectancy: > 30.000 h
OPTICS
  • Beam angle: without lens 120°, with lens 40°
  • Field angle: without lens 150°, with lens 80°
  • Other: Mountable 40° lens reflector plate (included)
COLOUR SYSTEM
  • Colour mixing: RGBW / FC
  • White presets: 2.800 K -10.000K
  • Colour wheel: virtual colour wheel with macros
DYNAMIC EFFECTS
  • Rotating gobos: dynamic patterns with speed and rotation control
  • Pixel patterns: pre-programmed dynamic and static patterns
  • FX generator: adjustable foreground/background colour, index, speed, direction
  • Static mode: selection of static colour
  • Manual mode: manual adjustment of colour
  • Auto mode: built-in programs with execution speed adjustment
  • Special features: Multi-layer pixel FX control
BODY
  • Hardware on-board: sockets for quick-Lock Omega bracket (clamp not included)
  • Body: sturdy die-cast aluminium body
  • Body colour: black
CONTROL
  • Protocols: DMX512, RDM, Art-Net, Kling-Net
  • DMX channels: from 4 ch to 87channel
  • Pixel control: 1 / 2 / 4 / 8 / 16 individually select and control sections
  • RDM: RDM for remote monitoring and settings
  • Display: black TFT touch display
  • Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
ELECTRONICS
  • Dimmer: linear 0 ~ 100% electronic dimmer
  • Dimmer curves: 4 selectable dimming modes available
  • Strobe / shutter: 1 - 30 Hz, electronic
  • Operating temperature: -10° ~ +45°
  • Selectable PWM: 600 ~ 25.000 Hz
ELECTRICAL
  • Mains power supply: 100-240V - 50/60Hz
  • Max power consumption: strobe: 987 W - static: 600W
  • Max power consumption (at 120V): strobe: 1.065 W - static: 630W
  • Output (at 230V): 3 units on a single power line
  • Output (at 120V): 1 units on a single power line
PHYSICAL
  • IP rating: 20
  • Cooling: active, silent operation
  • Suspension and fixing: hanging bracket for floor positioning with "Quick-Lock" system
  • Signal connection: Amphenol XLR 5p IN/OUT connectors
  • Data connection: Art-Net RJ45 IN/OUT
  • Power connection: Seetronic powerCON waterproof IN/OUT connectors
  • Dimensions (WxHxD): 1.000x75x231mm
  • Weight: 9,5kg
Supplier SKU
SUNBAR2000FC
