JET SPOT 120

Name: JET SPOT 120
Brand: Prolights

530005430

120W Spot Moving head, with 9° - 46° zoom

Beskrivelse Specification Brand information Downloads

Jet Spot120

is a budget friendly, zoomable, and compact moving spotlight, making it a perfect fit for various venues and corporate events with its compact form factors.

Jet Spot120 delivers remarkable flexibility with its motorized zoom, which ranges from 9° to 46°. The 120W white LED source produces a surprising 5.600 lumen fixture output.

The effect section includes one color wheel, one rotating and one static gobo wheel, prism and frost, meeting the creative demands of lighting designers.

Technical Specifications

LIGHT SOURCE

Source: 120W high-power white LED
CCT: 7.500K
Luminous flux: (9,1°) 4'502 lm - (46,3°) 5'686 lm @Full
Lux: (9,1°) 9'452 lx - (46,3°) 681lx @5 m full
Source life expectancy: > 30.000 h

OPTICS

Zoom range: 9,1° - 46,3° motorised linear zoom
Lens diameter: 75mm Lens type: HD anti-reflection lenses with achromatic coating
Focus: motorised

COLOUR SYSTEM

CCT: on wheel 3.200 K
Colour wheel: open+8 colour filters

DYNAMIC EFFECTS

Control Resolution: 16-bit dimmer
Rotating gobos: 7 rotating gobos + open, interchangeable, indexing
Gobo size: 22,5 mm - image: 17 mm - thickness: up to 3 mm Fixed gobos: 10 fixed gobos + open
Circular prism: 3f with bi-directional rotation, indexing, interchangeable
Frost: linear 0 - 100% light frost filter, interchangeable

BODY

Hardware on-board: sockets for quick-Lock Omega bracket (clamp not included)Pan range: 540° Tilt range: 260° Pan/Tilt resolution: bit 16-bitFeedback: automatic repositioning after accidental movement
Body: aluminium structure with high-resistance polycarbonate cover
Body colour: RAL 9004

CONTROL

Protocols: DMX512, RDM
DMX channels: 20channel
RDM: RDM for remote monitoring and settings
Display: LCD high resolution colour display with autoflip
Firmware upgrade: via DMX with UPBOXPRO/UPBOX2 (USB-DMX interface not included) or via USB pen drive

ELECTRONICS

Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: 4 selectable dimming modes available
Strobe / shutter: 1 - 30 Hz, electronic
Display battery: self-charging battery backup
Operating temperature: -10° ~ +45° TaLED Control: flicker free frequency with adjustable PWM
Selectable PWM: 600 ~ 50.000 Hz

ELECTRICAL

Mains power supply: 100-240V - 50/60Hz
Max power consumption: 238W Standby power: 50,2 W Output (at 230V): 16 units on a single power line
Power factor: > 0,94

PHYSICAL

IP rating: 20 Cooling: active, silent operation
Suspension and fixing: any position with quick-lock omega bracketsSignal connection: Neutrik XLR 5p IN/OUT connectors
Power connection: Seetronic powerCON TRUE IP65 IN/OUT
Dimensions (WxHxD): 340 x 479 x 205mm
Weight: 13,5kg

CERTIFICATIONS / APPROVALS

Certifications / Approvals: CE, RCM

Supplier SKU

JETSPOT120
