MOSAICO L- IP66 LED Image Projector

530020100

300 W IP66 zoomable LED image projector with Animation wheel and framing shutter

Beskrivelse Specification Brand information Downloads

The Mosaico L is a bright outdoor LED image projector, designed for long-range image, textures and logo projections.

Built in a durable IP66 die-cast housing, the Mosaico L offers a phenomenal output of 11,700 lumens and an extensive set of features including a rotating animation wheel, 7 interchangeable gobos, and motorized framing shutters that precisely focus within a certain projection area.

It has an exceptional zoom range, from 7° to 49°, making it versatile in both near-field and long-throw installations, or even for static and animated facade building lighting.

Technical Specifications

LIGHT SOURCE

Source: 300W high-power white LED
CCT: 8.000K
Luminous flux:

(7°) 8'536 lm - (49°) 11'729lm @full
Lux: (7°) 28'230 lx - (49°) 867 lx @5 m full
Source life expectancy: > 20.000 h

OPTICS

Zoom: 7°- 49° motorised linear zoom
Lens diameter: 110 mm
Lens type: HD anti-reflection lenses with achromatic coating
Focus: motorised

COLOUR SYSTEM

Colour mixing: cold white LED with colour wheel
Colour wheel: open + 7 colour filters

DYNAMIC EFFECTS

Control Resolution: 16-bit dimmer
Shutter system: 4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete framing system
Animation wheel: magnetic interchangeable animation wheel with CW and CCW rotation
Rotating gobos: open + 7 rotating gobos + open, interchangeable, indexing
Gobo size (BW): outer: 26,9 mm - image: 23 mm
Gobo size (Color): outer: 26,9 mm - image: 20,5 mm
FX generator: shutter macros with adjustable speed Circular prism:3f , with bi-directional rotation, indexing
Frost:linear 0 - 100% frost filter
Special features: record scenes and create chases and shows throughout these scenes

BODY

Body: weatherproof IP66 construction
Body colour: RAL 9006
Other: Inspectable cover window for gobos replacement and maintenance

CONTROL

Protocols: DMX512, RDM, W-DMX
Stand Alone: Stand Alone programmer and playback
DMX channels: 22 / 32 / 43channel
Wireless Control: included, Lumen Radio Timo Fx DMX/RDM compatible with both CRMX (Lumen Radio) and W-DMX (Wireless DMX)
RDM: RDM for remote monitoring and settings
Display: Graphic User Interface
Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included

ELECTRONICS

Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: 4 selectable dimming modes available
Strobe / shutter: 1~30 Hz, electronic
Display battery: self-charging battery backup
Operating temperature: -20° C / +45° C (-4° F / +113° F)
LED Control: flicker free frequency with adjustable PWM
Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

Mains power supply: 100-240V - 50/60Hz
Max power consumption: 440W
Output (at 230V): 4 units on a single power line
Power factor: > 0,98

PHYSICAL

IP rating: 66 for outdoor installations
Cooling: combination of heat pipe cooling system and low noise fan
Suspension and fixing: bracket for hanging and positioning
Adaptors: XLR and Schuko 16A adaptors included
Signal connection: moulded IP signal IN/OUT connectors
Data connection: W-DMX transreceiver
Power connection: moulded IP power IN/OUT connectors
Dimensions (WxHxD): 362x428x451mm
Weight: 25 kg

CERTIFICATIONS / APPROVALS

Certifications / Approvals: CE, UKCA, RCM, cTUVus, FCC
